Machinery Qhov muag Bolts

Txheem: DIN 580
Xov Hom: Coarse Xov
Khoom siv: Machinery Eye Bolts
Kuj hu ua: Steel Qhov Muag Screws
Khoom siv: Carbon Steel
Loj: M6, M8, M10, M12, M14, M16, M18, M20, M22, M24, M27, M30, M33, M36, M39, M42, M45, M48, M52, M56, M60, M64, M72 × 6, M80 × 6, M100 × 6
Nto: Plain, Dub Oxide, Zinc Plated, Kub Dipped Galvanized, Oxidation, Dacromet, Phosphating, Cadmium Electrolate, Nickel Plated
Hom Lub Taub Hau: Nrog Lifting Qhov Muag
Tsav hom: Nrog Tes
MOQ: 1000kgs
Lub Sijhawm Lead: 30-60 hnub

Xa kev nug

Khoom Taw qhia

Eye Bolts-AYA Screws

Raws li lub ntiaj teb cov khoom lag luam ntawm cov kev daws teeb meem fastening, AYA cov txheej txheem senvice kuj yog ze rau cov neeg siv khoom raws li AYA cov khoom. Los ntawm kev piav qhia txog kev xav tau kev pab cuam tom qab, AYA yuav sai sai thiab tsis muaj kev siv dag zog los pab cov neeg siv khoom daws teeb meem uas tshwm sim, tshem tawm cov kev txhawj xeeb ntawm cov neeg siv khoom.

KHOOM PLIG

Khoom npe	Machinery Qhov muag Bolts
Kuj hu ua	Hlau Qhov Muag Screws
Khoom siv	Cov pa roj carbonHlau
Txuj	TIAB SA 580
Txoj kab uas hla	M6, M8, M10, M12, M14, M16, M18, M20, M22, M24, M27, M30, M33, M36, M39, M42, M45, M48, M52, M56, M60, M64, M72×6, M80×6, M100×6
Ua kom tiav	Plain,Dub Oxide,Zinc Plated,Kub Dipped Galvanized, Oxidation, Dacromet,Phosphating,Cadmium electroplates,Nickel Plated
Hom Lub taub hau	Nrog Lifting Eye
Tsav hom	Nrog Tes
Xov Hom	Xov xwm

DIMENSION TABLE

Machinery Eye Bolts 2D

Specifications
d		M6	M8	M10	M12	M14	M16	M18	M20	M22
d		M6	M8	M10	M12	M14	M16	M18	M20	M22
d2	Nominal Loj	20	20	25	30	35	35	40	40	50
	min	19.5	19.5	24.5	29.5	34.5	34.5	39.5	39.5	49.4
	max	20.9	20.9	25.9	30.9	36.1	36.1	41.1	41.1	51.2
d3	Nominal Loj	36	36	45	54	63	63	72	72	90
	min	35.5	35.5	44.5	53.5	62.5	62.5	71.5	71.5	89.4
	max	37.1	37.1	46.1	55.1	64.1	64.1	73.1	73.1	91.2
d4	Nominal Loj	20	20	25	30	35	35	40	40	50
	min	19.1	19.1	24.1	29.1	33.9	33.9	38.9	38.9	48.8
	max	20.5	20.5	25.5	30.5	35.5	35.5	40.5	40.5	50.6
e	Nominal Loj	6	6	8	10	12	12	14	14	18
	min	5.5	5.5	7.5	9.5	11.5	11.5	13.5	13.5	17.5
	max	6.9	6.9	8.9	10.9	12.9	12.9	14.9	14.9	19.1
f	max	2.5	2.5	3	3.5	4	4	5	5	6
ds	max=nominal loj (h15)	4.4	6	7.7	9.4	11	13	14.4	16.4	18.4
ds	min	4.22	5.82	7.48	9.18	10.73	12.73	14.13	16.13	18.07
h	Nominal Loj	36	36	45	53	62	62	71	71	90
	min	35.5	35.5	44.5	52.5	61.5	61.5	70.5	70.5	89.4
	max	37.1	37.1	46.1	54.1	63.1	63.1	72.1	72.1	91.2
k	Nominal Loj	8	8	10	12	14	14	16	16	20
	min	7.5	7.5	9.5	11.5	13.5	13.5	15.5	15.5	19.5
	max	8.9	8.9	10.9	12.9	14.9	14.9	16.9	16.9	21.1
L	Nominal Loj (js15)	13	13	17	20.5	27	27	30	30	36
	min	12.65	12.65	16.65	20.08	26.58	26.58	29.58	29.58	35.5
	max	13.35	13.35	17.35	20.92	27.42	27.42	30.42	30.42	36.5
m	Nominal Loj	10	10	12	14	16	16	19	19	24
	min	9.5	9.5	11.5	13.5	15.5	15.5	18.5	18.5	23.5
	max	10.9	10.9	12.9	14.9	16.9	16.9	19.9	19.9	25.1
r	≈	4	4	4	6	6	6	8	8	12
Nyob rau hauv ib chav tsev ≈ kg		0.0572	0.06	0.11	0.18	0.27	0.28	0.438	0.45	0.725
Specifications
d		M24	M27	M30	M33	M36	M39	M42	M45	M48
d		M24	M27	M30	M33	M36	M39	M42	M45	M48
d2	Nominal Loj	50	65	65	75	75	85	85	100	100
	min	49.4	64.3	64.3	74.3	74.3	84.3	84.3	99.2	99.2
	max	51.2	66.3	66.3	76.5	76.5	86.5	86.5	101.7	101.7
d3	Nominal Loj	90	108	108	126	126	144	144	166	166
	min	89.4	107.3	107.3	125.2	125.2	143.2	143.2	164.9	164.9
	max	91.2	109.5	109.5	127.7	127.7	145.7	145.7	168.1	168.1
d4	Nominal Loj	50	60	60	70	70	80	80	90	90
	min	48.8	58.7	58.7	68.5	68.5	78.5	78.5	88.3	88.3
	max	50.6	60.7	60.7	70.7	70.7	80.7	80.7	90.8	90.8
e	Nominal Loj	18	22	22	26	26	30	30	35	35
	min	17.5	21.4	21.4	25.3	25.3	29.3	29.3	34.2	34.2
	max	19.1	23.2	23.2	27.3	27.3	31.3	31.3	36.7	36.7
f	max	6	7	7	8	8	9	9	10	10
ds	max=nominal loj (h15)	19.6	22.6	25	28	30.3	33.3	35.6	38.6	41
ds	min	19.27	22.29	24.67	27.61	29.91	32.91	35.21	38.21	40.61
h	Nominal Loj	90	109	109	128	128	147	147	168	168
	min	89.4	108.3	108.3	127.2	127.2	146.2	146.2	166.9	166.9
	max	91.2	110.5	110.5	129.7	129.7	148.7	148.7	170.1	170.1
k	Nominal Loj	20	24	24	28	28	32	32	38	38
	min	19.5	23.4	23.4	27.3	27.3	31.3	31.3	37.2	37.2
	max	21.1	25.2	25.2	29.3	29.3	33.3	33.3	39.7	39.7
L	Nominal Loj (js15)	36	45	45	54	54	63	63	68	68
	min	35.5	44.5	44.5	53.5	53.5	62.4	62.4	67.4	67.4
	max	36.5	45.5	45.5	54.5	54.5	63.6	63.6	68.6	68.6
m	Nominal Loj	24	28	28	32	32	38	38	46	46
	min	23.5	27.4	27.4	31.3	31.3	37.3	37.3	45.2	45.2
	max	25.1	29.2	29.2	33.3	33.3	39.5	39.5	47.7	47.7
r	≈	12	15	15	18	18	20	20	22	22
Nyob rau hauv ib chav tsev ≈ kg		0.74	1.624	1.66	2.596	2.65	3.78	4.03	6.244	6.38
Specifications
d		M52	M56	M60	M64	M72×6	M80×6	M100×6	-	-
d		M52	M56	M60	M64	M72×6	M80×6	M100×6	-	-
d2	Nominal Loj	110	110	120	120	150	170	190	-	-
	min	108.9	108.9	118.9	118.9	148.8	168.5	188.5	-	-
	max	112.1	112.1	122.1	122.1	152.4	173	193	-	-
d3	Nominal Loj	184	184	206	206	260	296	330	-	-
	min	182.8	182.8	204.8	204.8	258.5	294.3	328.3	-	-
	max	186.4	186.4	208.4	208.4	263	299.3	333.3	-	-
d4	Nominal Loj	100	100	110	110	140	160	180	-	-
	min	98.1	98.1	107.9	107.9	137.6	157.3	177	-	-
	max	100.9	100.9	111.1	111.1	141.2	161.3	181.5	-	-
e	Nominal Loj	38	38	42	42	50	55	60	-	-
	min	37.1	37.1	41.1	41.1	48.9	53.8	58.8	-	-
	max	39.9	39.9	43.9	43.9	52.1	57.4	62.4	-	-
f	max	11	11	12	12	12	12	12	-	-
ds	max=nominal loj (h15)	45	48.3	52.3	55.7	63.7	71.7	91.7	-	-
ds	min	44.54	47.91	51.84	55.24	63.24	71.24	91.16	-	-
h	Nominal Loj	187	187	208	208	260	298	330	-	-
	min	185.8	185.8	206.8	206.8	258.5	296.3	328.3	-	-
	max	189.4	189.4	210.4	210.4	263	301.3	333.3	-	-
k	Nominal Loj	42	42	48	48	60	68	75	-	-
	min	41.1	41.1	47.1	47.1	58.9	66.8	73.8	-	-
	max	43.9	43.9	49.9	49.9	62.1	70.4	77.4	-	-
L	Nominal Loj (js15)	78	78	90	90	100	112	130	-	-
	min	77.4	77.4	89.3	89.3	99.3	111.3	129.2	-	-
	max	78.6	78.6	90.7	90.7	100.7	112.7	130.8	-	-
m	Nominal Loj	50	50	58	58	72	80	88	-	-
	min	49.1	49.1	57.1	57.1	70.9	78.8	86.8	-	-
	max	51.9	51.9	59.9	59.9	74.1	82.4	90.4	-	-
r	≈	25	25	25	25	35	35	40	-	-
Nyob rau hauv ib chav tsev ≈ kg		8.566	8.8	12.13	12.4	23.3	34.2	49.1	-	-

KHOOM NTAUB NTAWV

Machinery Eye Bolts details

KHOOM ZOO TSHAJ PLAWS

Machinery Eye Bolts advantages

Qhov zoo ntawm Machinery Qhov muag Bolts

1. Machinery qhov muag bolts tsis tshua kim tshaj qhov muag muag.

2. Machinery qhov muag bolts yog cov khoom siv yooj yim uas tsis muaj qhov txav txav.

3. Forged steel qhov muag bolts yog qhov yooj yim kawm paub siv thiab pom qhov muag.

4. Machinery qhov muag bolts feem ntau yog siv los ntsia hlau rau hauv cov khoom siv los ua cov ntsiab lus nqa.

5. AYA muaj ntau qhov ntau thiab tsawg ntawm cov screws kom tau raws li qhov xav tau ntau.

QUALITY INSPECTION

Quality Check-AYA Fasteners

1. Cov neeg soj ntsuam QC tau paub zoo txog cov khoom lag luam kev paub nrog rau cov txheej txheem tsim khoom. Cov cuab yeej tshwj xeeb yog siv los ua ntau yam kev sim kom ntseeg tau tias cov khoom kawg tuaj yeem ua tau raws li cov kev xav tau ntawm kev ua lag luam thiab cov neeg siv khoom.

2. AYA muaj lub chaw soj ntsuam zoo tshaj plaws rau QC ntawm cov khoom siv raw thiab cov khoom tiav tiav. Peb cov khoom yog tsim nruj me ntsis raws li cov kev cai ntawm cov neeg siv khoom thiab kev lag luam. Tag nrho cov ntsiab lus tseem ceeb yog optimized los tsim cov txheej txheem ntau lawm.

PACKAGING & CONTAINER LOADING

Packing-AYA Fasteners

1. Lub ntim tuaj yeem hloov kho raws li cov neeg siv khoom xav tau. Thiab nws yuav muaj zog ntxiv los tiv thaiv kev puas tsuaj uas tsis tau npaj tseg thaum lub sijhawm xa khoom.

2. Automated packing kab txhim kho qhov zoo thiab ceev ntawm kev ntim khoom.

SIV SCENARIOS

Usage-AYA Fasteners
